S105-3 | 3/8" Female Half Double Shut-Off Quick Coupling

Material Steel
Valve Type Poppet (O-ring Seal)
Seal Material Nitrile (Buna-N)
Temperature Range (å¼F) -40 to 250
Coupler Size (Inch) 3/8
Coupler Size (mm) 10.0
Rated Flow (GPM) 6.0
Rated Flow (L/Min) 23
Industry Standard Numbers ISO7241-1 Series B
Body Length (Inch) 2.480
Diameter (Inch) 1.390
Wrench Flat (Inch) 0.870
Diameter (Inch) 1.000
Description Body Half
Thread 3/8 Female Pipe
Body Size (in) 3/8
Maximum Operating Pressure (psi) 4,000
Lock Style Ball
Industry Applications Chemical Processing
Food and Beverage
Industrial Plants
Maintenance and Repair Operations
Marine and Defense
Oil and Gas

Call for Price
